SRP（Self Reinforced Plastics）
KaRVO™
New lightweight, repulsive and shock resistant material created with stretching technology and weaving technology
KaRVO™ = Karui (“light”) + Revolution
Features
- Lightweight: made of polypropylene, light enough to float on water
- Highly repulsive and assisting: ideal for footwear
- Resistant to shock and bending: hard to crack
- Allows thermoforming or sewing: Excellent Formability, e.g., bending with heat or sewing and inserting metal eyelets
- Thermoplastic resin: recyclable = consideration for the SDGs
Applications
・Taking advantage of lightweight and crushproof properties: suitcases, bags
・Taking advantage of repulsive property: sport shoes, insoles
・Taking advantage of lightweight and high stiffness: logistics materials
Product specifications
| Item | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Color | Silver | ||||||||
| Silver/Black | |||||||||
| Black | |||||||||
| Dimension | Size (width x length) | 1100mm × 1100ｍｍ | Maximum length 2000 mm (Consult for details.) Narrow width available (Consult for details.) |
||||||
| Thickness | 0.6, 0.9, 1.2, 1.5, 1.8mm | ||||||||
| Surface decoration (optional) |
PET nonwoven fabric PET film |
Product width can be narrow depending on the surface material. | |||||||
Physical properties
| Method of testing | Unit | KaRVO™ | PP | CFRP | GFRP | PA66 | ABS | PC |
|---|---|---|---|---|---|---|---|---|
| Density | g/c㎥ | 0.83 | 0.9 | 1.5 | 1.5 | 1.2 | 1 | 1.2 |
| Flexural modulus (Referred to JIS K 7171) |
MPa | 1,700 | 1,550 | 40,000 | 19,000 | 2,400 | 2,100 | 1,250 |
| Bending fatigue resistance 50,000 times of 90° bending (ASTM D 1052) |
– | No damage | Cracked, whitened | Damaged | Damaged | Deformed, whitened | ||
| Weight-drop test (R4.76 in-house method) |
J/mm | 6.5 | 3.4 | 2.3 | 4.0 | 3.9 | 4.9 | 5.9 |
| Low-temperature shock resistance (cooled to −20 degrees Celsius and hit with a hammer) |
– | Not destroyed | Destroyed | Not destroyed | Not destroyed | Destroyed | Not destroyed | Not destroyed |
* Data are not guaranteed values but for reference only.
Usage
Shoes
Insoles
Protectors
Bags
